三八译码器真值表

A	B	C	output
0	0	0	0000_0001
0	0	1	0000_0010
0	1	0	0000_0100
0	1	1	0000_1000
1	0	0	0001_0000
1	0	1	0010_0000
1	1	0	0100_0000
1	1	1	1000_0000

代码编写

module Decoder3_8(a, b, c, out);
	input a;
	input b;
	input c;

	output [7:0]out;//定义多位位宽的信号

	always@(a,b,c)begin
		case({a,b,c})//用花括号位拼接
			3'b000:out = 8'b0000_0001;//下划线是占位符，不代表任何意思
			3'b001:out = 8'b0000_0010;
			3'b010:out = 8'b0000_0100;
			3'b011:out = 8'b0000_1000;
			3'b100:out = 8'b0001_0000;
			3'b101:out = 8'b0010_0000;
			3'b110:out = 8'b0100_0000;
			3'b111:out = 8'b1000_0000;
			//default:out = 8'b1000_0000;
		endcase
	end

endmodule

编译报错：Error (10137): Verilog HDL Procedural Assignment error at Decoder3_8.v(10): object "out" on left-hand side of assignment must have a variable data type

在always@()块中的输出信号一定要是reg型，所以output [7:0]out;修改成output reg [7:0]out;

/* 这样也行 output [7:0]out; reg [7:0]out; */

测试文件编写

`timescale 1ns/1ps//定义 延时和仿真 精度

module Decoder3_8_tb;

	reg a;//定义激励信号源
	reg b;//定义激励信号源
	reg c;//定义激励信号源

	wire [7:0] out;//定义观测信号源

	Decoder3_8 u1(
		.a(a), //一定要在a之前加上点
		.b(b),
		.c(c),
		.out(out)
	);

	initial begin
		a = 0;b = 0;c = 0;
		#100;
		a = 0;b = 0;c = 1;
		#100;
		a = 0;b = 1;c = 0;
		#100;
		a = 0;b = 1;c = 1;
		#100;
		a = 1;b = 0;c = 0;
		#100;
		a = 1;b = 0;c = 1;
		#100;
		a = 1;b = 1;c = 0;
		#100;
		a = 1;b = 1;c = 1;
		#200;
		$stop;
	end

endmodule
